ATD-WB1008:Foot Switch สวิตซ์เท้า


•Recommended installation height: 0.3 m height from the ground.
•Reaction time: relay output ≤45ms
•Supply power: AC/DC 12-36V
•Power consumption: 82mA
•Supervisory signal: 4.5S MA
•Signal direction: Indicator with red light when infrared ray emitted and received effectively. Indicator with green light when the infrared ray truncated by foot operated.
•Operation temperature: -20ºC~+55ºC
•Interference immunity: Sunlight 81000LUX
•Incandescent lamp: 36000LUX
•Electric Microwave: Consist with 89/336/CEE criteria
•Appearance dimensions:
123(L)×50(W)×32(H)mm ( Main controller)
19mm×13mm(Electric eyes)
186mm×175mm×53mm(Bracket)
•Output signal: Relay NO signal contact
•Total Weight: About 1000G
